Introduction

This is a breakout board for Free scale's MMA7361L three-axis analog accelerometer. The sensor requires lower power and has a g-select input which switches the accelerometer between ±1.5g and ±6g measurement ranges. Other features include a sleep mode, signal conditioning, a 1-pole low pass filter, temperature compensation, self test, and 0g-detect which detects linear freefall. Zero-g offset and sensitivity are factory set and require no external devices.

Features

Two selectable measuring ranges (±1.5g, ±6g)

Low current consumption: 400 µASleep mode: 3 µA

Low voltage operation: 2.2 V - 3.6 V

High sensitivity (800 mV/g at 1.5g)

Fast turn on time (0.5 ms enable response time)

Dimensions: 28 * 17mm
